Subwoofer Speaker
HL-38AS | 3200W Class-D Flyable 18" Subwoofer
Item No.: HL-38AS
136 dB Max SPL
3200W peak class-D Amplifier
30-140 Hz frequency response
RDNet Control Optional
48.7 kg / 107.36 lbs
3200W peak class-D Amplifier
30-140 Hz frequency response
RDNet Control Optional
48.7 kg / 107.36 lbs
Description
|
ACOUSTICAL SPECIFICATIONS
|
|
|
Frequency Response
|
30 Hz - 140 Hz
|
|
Max SPL @ 1m
|
136 dB
|
|
TRANSDUCERS
|
|
|
Woofer
|
1 x 18" neo, 4.0" v.c
|
|
INPUT/OUTPUT SECTION
|
|
|
Input signal
|
bal/unbal
|
|
Input connectors
|
XLR, RDNet Ethercon
|
|
Output connectors
|
XLR, RDNet Ethercon
|
|
Input sensitivity
|
+4 dBu
|
|
PROCESSOR SECTION
|
|
|
Protections
|
Thermal, RMS
|
|
Limiter
|
Soft Limiter
|
|
Controls
|
Volume, Preset selection
|
|
RDNet
|
Onboard
|
|
POWER SECTION
|
|
|
Total Power
|
3200 W Peak, 1600 W RMS
|
|
Low frequencies
|
3200 W Peak, 1600 W RMS
|
|
Cooling
|
Convection
|
|
Connections
|
Powercon IN/OUT
|
|
PHYSICAL SPECIFICATIONS
|
|
|
Cabinet/Case Material
|
Baltic birch plywood
|
|
Hardware
|
Array fittings
|
|
1 X M20
|
|
|
Handles
|
2 Side
|
|
Pole mount/Cap
|
M20 thread
|
|
Grille
|
Steel
|
|
Color
|
Black
|
|
SIZE / WEIGHT
|
|
|
HxWxD
|
502 mm ×700 mm × 621mm
|
|
Weight
|
48.7 kg / 107.36 lbs
|
FEATURE
| The HL-38AS is the ideal flyable bass complement for the HL-30A array system. It features one 4.0” voice coil, 18” Neodymium woofer to handle 136 dB SPL Max from 30 Hz to 140 Hz with the maximum linearity and low distortion. The HL-38AS is perfect to create flown systems for theatrical and indoor requirements. The built-in 3200W class-D amplifier delivers excellent playback clarity and up to 136 decibels SPL max. Due to its compatibility with RDNet - remote monitoring and control, the HL-38AS is part of the professional HL System. |
